Mini Dumper
Language
The Mini Crawler Dumper can adapt to complex and harsh road conditions such as rice fields, swamps, muddy field roads, rugged mountain roads, soft grass and deserts, slippery ice and snow, etc. , Infrastructure engineering, mining sites are widely used.
Body Weight ：75kg
Maximum Load ：150kg
Body Length(L*W*H)：1900*680*790mm
Fuel tank volume： 1.6L
Reverse gear ：1.65km/h
 |  |
 |  |
 |  |
1. Wide range of use, simple structure, smooth transmission, labor-saving operation, and easy to realize automatic control.
2. It is suitable for complex road conditions such as swamps, river beaches, deserts, paddy fields, tropical rain forests, snow and ice.
3. Large traction, good climbing performance and strong transportation capacity.
4. Small turning radius, flexible and flexible, especially suitable for narrow sites, reducing the cost of road construction.
Name Model | GMC150 | ||
Body weight | 75kg | ||
Gross weight | 151kg | ||
Maximum load | 150kg | ||
Body LxWxH | 1900x680x790mm | ||
Track ground surface length | 450mm | ||
Track width | 150mm | ||
Cargo box table size | 900x800 | ||
Engine Name | GM156 | ||
Total displacement | 98.5ml | ||
Rated power | 1.5/3600kw/rpm | ||
Use fuel | 93 unleaded gasoline | ||
Fuel consumption | ≤0.374g/kw.h | ||
Fuel tank volume | 1.6L | ||
Oil capacity | 0.36L | ||
Forward fast gear | 2.7km/h | ||
Forward fast gear | 2.7km/h | ||
Reverse gear | 1.65km/h | ||
Gradeability | 20° | ||
Transmission oil quantity | 0.3L | ||
Package size(LXWXH) | 1530x750x750mm |
