Mini Dumper
Language
The Mini Crawler Dumper can adapt to complex and harsh road conditions such as rice fields, swamps, muddy field roads, rugged mountain roads, soft grass and deserts, slippery ice and snow, etc. , Infrastructure engineering, mining sites are widely used.
Total Weight：330kg
Max Loading Weight：500kg
Rated Power：4.2 kw / 3600 rpm
Tipping Angle：42°
Machine Size(L*W*H)：1730x900x1110mm
 |  |
 |  |
 |  |
1. Wide range of use, simple structure, smooth transmission, labor-saving operation, and easy to realize automatic control.
2. It is suitable for complex road conditions such as swamps, river beaches, deserts, paddy fields, tropical rain forests, snow and ice.
3. Large traction, good climbing performance and strong transportation capacity.
4. Small turning radius, flexible and flexible, especially suitable for narrow sites, reducing the cost of road construction.
| Engine Model | GM170F |
| Engine Type | Single Cylinder, OHV, 4 Strokes, Air Cooling |
| Displacement | 208cc |
| Rated Power | 4.2 kw / 3600 rpm |
| Fuel Type | 92 # Gasoline |
| Fuel Consumption | ≤0.395 g/kw.h |
| Fuel Tank Capacity | 3.6L |
| Engine Oil Capacity | 0.6L |
| Total Weight | 330kg |
| Max Loading Weight | 500kg |
| Machine Size | 1730x900x1110mm |
| Cargo box Capacity | 220dm³ |
| Tipping Systme | Hydraulic |
| Track Ground Length | 830mm |
| Track grage | 622mm |
| Track Width | 180mm |
| Tipping Angle | 42° |
| Walking Speed | 0-7.8km/h |
| Minimum Turning Radius | 1.15m |
| Minimum Ground Clearance | 100mm |
| Gearbox Oil Model | GL-4 |
| Gearbox Capacity | 2.5L |
| Hydraulic Oil Model | 46# Anti-wear Hydraulic Oil |
| Hydraulic Oil Tank Capacity | 5L |
| Climbing Ability | 20° |
